Description
Glass epoxy laminates and machined components are essential in heavy electrical applications, offering an outstanding blend of mechanical, electrical, and thermal properties. These components are crafted from a durable composite material comprising woven glass fibers embedded in an epoxy resin matrix, ensuring reliability and precision.
Key Properties:
- Superior Electrical Insulation: High dielectric strength, low dielectric loss, and excellent arc resistance, ideal for high-voltage applications.
- Exceptional Mechanical Strength: High tensile strength, compressive strength, and impact resistance ensure performance in demanding environments.
- Dimensional Stability: Low thermal expansion coefficient ensures precise dimensions and minimal distortion under temperature variations.
- Chemical Resistance: Resistant to acids, alkalis, and solvents for long-term durability in harsh conditions.
- Thermal Stability: Reliable operation in high-temperature environments with consistent performance.
Applications in Heavy Electricals:
- Switchgear: Insulates components in high-voltage switchgear, circuit breakers, and disconnectors.
- Transformers: Used in transformer bushings, spacers, and supports for enhanced performance.
- Motors and Generators: Provides insulation for windings, spacers, and other critical parts to ensure reliability.
- High-Voltage Transmission Lines: Utilized in insulators and components for overhead transmission systems.
- Electrical Enclosures: Fabricates durable and reliable housings for various electrical equipment.
Glass epoxy laminates deliver superior performance, making them indispensable for heavy electrical applications. Their exceptional properties ensure durability, precision, and efficiency in even the most challenging conditions. Contact us to learn more or request a custom solution.
Following Grades are available:
| Material Name | NEMA Reference | IEC Reference | Safety Data Sheet |
|---|---|---|---|
| G-10 | NEMA G-10 | EPGC 201 | G-10 SDS |
| G-11 | NEMA G-11 | EPGC 203 | G-11 SDS |
| G-11H (Glass Epoxy Laminate) | NEMA G-12 | EPGC 308 | G-11H SDS |
| G-11 (PTFE Coated) | NEMA G-11 | EPGC 203 | G-11 (PTFE Coated) SDS |
| G11R (Glass Epoxy Laminate) | — | EPGC 205 | G11R SDS |
| G-13 | NEMA G-13 | — | G-13 SDS |
| FR4 | NEMA FR4 | EPGC 202 | NEMA FR4 SDS |
| G-3 | NEMA G-3 | PFGC 301 | NEMA G-3 SDS |
| G-7 | NEMA G-7 | SIGC 202 | NEMA G-7 SDS |
| G-9 | NEMA G-9 | MFGC 201 | NEMA G-9 SDS |
| G-11 (Formable) | NEMA G-11 | EPGC 203 | G-11 SDS |
Data Sheets will be provided on request
